ADJ

Protege XS

Compact in size yet mighty in performance, the ADJ Protégé XS is a next-generation LED-powered Beam/Spot/Wash moving head spot luminaire that delivers exceptional creative…

Review quote request
View on ADJ site

Overview

Compact in size yet mighty in performance, the ADJ Protégé XS is a

Specifications

Source:

  • 250W White LED Engine
  • Color Temperature: 8500K (+/-200K)
  • 20,000 Hour Average LED Life*
  • *May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.

Photometric Data:

  • 9,800 Lumens
  • CRI: 73

Color:

  • 2 x Color Wheels
  • 8 Colors per Color Wheel
  • Color Wheel 1: Red, Blue, Green, Orange, Quad Color, Yellow, Magenta, Congo Blue
  • Color Wheel 2: Dark Red, Light Turquoise, UV, Pink, Quad Color, Lavender, CTO 3200K, CTB 9000K

Gobos:

  • 1 x Rotating Gobo Wheel: 7 Interchangeable Glass Gobos (OD: 16mm, Image: 10mm)
  • 1 x Static Gobo Wheel: 11 Fixed Aluminum Gobos, Including Two Beam Reducers

Effects:

  • Motorized Zoom: 4.8° ~ 38°
  • 2 x Prisms: 1 x 6-Facet Linear & 1 x 6-Facet Circular (Overlay Capable)
  • Heavy Frost Filter for Smooth Wash Effects
  • Animation Wheel on Movable Arm
  • Motorized Focus
  • 1Hz ~ 10Hz Strobe Rate (Electronic)

Control / Connections:

  • 3 DMX Channel Modes (Basic / Standard / Extended)
  • DMX, RDM
  • Aria X2 Wireless Management System
  • NFC System
  • 6-Button Touch Control Panel
  • Full Color 180° Reversible LCD Menu Display
  • 8 / 16-Bit Resolution Adjustable Movement
  • 5-pin XLR DMX In/Out
  • IP65 Locking Power In/Out

Pan / Tilt:

  • Pan: 540°/630° and 360° Continuous Pan Rotation
  • Tilt: 270°
  • Pan/Tilt Locks
  • 3-Phase Motors

Size / Weight:

  • Length: 364mm
  • Width: 248mm
  • Vertical Height: 509mm
  • Weight: 17.85kg

Electrical / Thermal:

  • AC 100–240V, 50/60Hz
  • Max Power Consumption: 616W
  • Power Link: 5 Units @ 230V
  • Max Ambient Temperature: -25°C to 45°C
  • Max Housing Temperature: ?°C

Technical Data:

  • DB Rating @ 1m: ?dB
  • BTU: ?
  • BTU/H: ?
