ADJ
AV6X
6mm pixel pitch, High Resolution video panel.
View on ADJ siteOverview
6mm pixel pitch, High Resolution video panel. 576x576mm. Locking Power In & out, Locking RJ45 In & out. Novastar receiving card. IMPROVED MASK FOR HIGHER CONTRAST AND IMPROVED LED FOR BETTER QUALITY AND COLOR CONSISTENCY.
Gallery
<div class="d-flex justify-content-center galleryImage" data-src="https://www.adj.eu/media/catalog/product/cache/2d30c628ca84d1fb5bde9dd708affbe5/a/v/av6xfx2jpg.jpg_5_1.jpg" data-bs-toggle="modal" data-bs-target="#myGalleryModal"
Video
Specifications
Source
- Light Source: RGB SMD2121 LEDs
- Pixel Density : 96 x 96 pixels, 27777 per square meter
- Average LED lifetime/MTBF : 100,000 hrs./5,000 hrs.
- Pixel Pitch: 6mm
Optics
- Brightness: 1200 NITS
- View Angle: Horizontal 140°/Vertical 140°
- Gray Scale / Display Color: 14-bit
- Brightness Adjustment: 0~100% 100 Levels
- Processing: 14-bit
Control
- Built-In Novastar Receiving Card
- LED Refresh Rate: 1200Hz
- Control Distance: Ethernet Cable 120m
- Optional Novastar Sending Cards and Accessories available
Colors
- RGB
Construction
- Aluminium Frame
- Module Quantity: 4
- Module Size : 288 x 288mm
- IP Rating: IP20 (Front & Back)
Electrical
- Multivoltage 100-240V 50/60Hz
- Max Power Consumption: 300W/panel
- Average Power Consumption: 120W/panel
- Operational temperature: -20 to +40 degrees
- Operational humidity: 10% — 90% (no condensation)
Connections
- Locking RJ45 In/Out connections
- Locking Power In/Out connections
