YME GT 9N: single 9" 2-way biamp coaxial passive line array speaker from the GT Line Array Series.
View on YME Systems siteOverview
The YME GT 9N is part of the YME GT Line Array Series — single 9" 2-way biamp coaxial passive line array speaker. Professional sound reinforcement from YME Systems, supplied and supported in the UAE by Pure Minds Trading, Dubai.
Specifications
Brand
- YME Systems
Model
- GT 9N
Series
- GT Line Array Series
Frequency Response
- 130 Hz ~ 16kHz (±3 dB); 95Hz ~ 20kHz (-10dB )
Nominal Dispersion(-6dB)
- 100° ×10°
Sensitivity(@1w / 1m)
- HF:108dB ,LF:96dB
Power Rating(AES)
- Hi:80W, Low:350W
Nominal Impedance
- Hi:16Ω, Low:16Ω
Maximum SPL
- Hi:127dB SPL，133dB SPL peak; Low:121dB SPL，127dB SPL peak
Drivers
- Hi:3"Tweeter, Neodymium; Low:9" (75mm Voice Coil , Neodymium.)
Dimensions (H x W x D)
- 302.5×250×298(mm)
Net Weight
- 12kg
Riggings
- 3 Fly Points + Pole Mounts
Connector
- NL4×2
Connection Method
- LF:1+1-, HF:2+2-
Enclosure
- 15mm Multilayer Birch Plywood
Finish
- Black polyurethane paint
Grille
- Black steel mesh + acoustic transparent cloth
