Single 15" Active Subwoofer Speaker. VS 15BA is the active version of VS 15B.
View on YME Systems siteOverview
VS 15BA is the active version of VS 15B.
Thanks to the superpower and multi-channels of the amplifier module of
YME
SYSTEMS（2X1000@4Ω + 1X2500@4Ω）, 1 active VS 15BA can drive 2 2 pieces full range speakers (VS 8 or VS 10-4) and another passive bass speaker VS 15B. Better than the ordinary satellite system (one active sub amplifying 2 passive full range speakers), VERSA active satellite system delivers more powerful low frequency in more affordable price.
Specifications
Brand
- YME Systems
Model
- VS 15BA
Series
- Versa Multipurpose Series
Frequency Response
- 50Hz--100Hz(±3dB); 45Hz--150Hz(-10dB)
Power Rating（AES）
- 600W
LF Driver
- 1x15" (75mm voice coil, ferrite)
Max. SPL
- 124dB SPL, 130dB SPL Peak
Dimensions （HxWxD）
- 468x545x600(mm)
Connection
- XLR+POWERCON+SPEAKON
Enclosure
- 15mm, 18mm M ultilayer Plywood
Riggings
- M8 x 12 + M20 Mount
Finishing
- B lack water-based paint
Grille
- B lack steel mesh + acoustic transparent cloth; 3 Channels D Class Switching Power Amplifier Module
4Ω
- 1000W 1000W 2500W
THD(1kHz, Full Power 4 Ω)
- ≤ 1% ≤ 1% ≤ 1%
SNR
- 102.5dB 103dB 103dB
Gain (1Khz,8Ω)
- 20dB 32dB 32dB
Input Method
- N eutrik & XLR male & XLR Female
I nput Impedance
- 20K Ω Banlanced/10k Ω Unbalanced
Input Connection (Full Range)
- Neutrik NL4MP ( LF: 1+1-, HF: 2+2-)
Input Connection (Subwoofer)
- Neutrik NL4MP (SUB: 1+1- )
O utput Circuit Type
- Class D
Cooling
- T he airflow direction is from the back to the front of the equipment
Voltage
- 200-240V ~ 50-60Hz
Supplied by
- Pure Minds Trading Co. LLC, Dubai, UAE
